2 Ton Per Day Apple Juice Processing Plant Beverage Processing Line

2 Ton Per Day Apple Juice Processing Plant Beverage Processing Line

    • 2 Ton Per Day Apple Juice Processing Plant Beverage Processing Line
    • 2 Ton Per Day Apple Juice Processing Plant Beverage Processing Line
  • 2 Ton Per Day Apple Juice Processing Plant Beverage Processing Line

    Product Details:

    Place of Origin: China (mainland)
    Brand Name: CFM
    Model Number: CFM-B-02-6001

    Payment & Shipping Terms:

    Minimum Order Quantity: 1Set
    Price: negotiable
    Packaging Details: Wooden Case
    Delivery Time: 100 Work Days
    Payment Terms: T/T, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability: 12 sets per year
    Contact Now
    Detailed Product Description
    Place Of Origin: Jiangsu,China(Mainland) Type: Beverage Processing Line
    Warranty: 360days Driven Type: Electric
    Automatic Grade: Automatic Feature: Energy Saving
    Material: SS304 Color: Silver
    High Light:

    apple juice processing line


    apple juice processing plant


    Apple pear  juice and jam  production line per hour
    Apple ,pear processing line quality assurance:

    1. The motor of Chenfei’s processing machine is basically ABB, Siemens and Jiangsu Dazhong.
    2. Stainless steel is from Zhangjiagang Pohang Stainless Steel Co., Ltd. (joint venture)
    3. The water pump is from Nanfang and the centrifugal pump is from Yuanan.
    4. Electrical cabinet and PLC control system: Siemens PLC touch screen, switch and AC contactor electrical protection is Schneider, intermediate relays are Honeywell.
    5. The 304 pipes we use for the pipeline is from Yuan'an, the cables are all good cables;

    ​​Technical advantage
      Taking into account the actual requirements of the customer's factory and the project equipment, the installation and positioning of the production line equipment adopts segmentation positioning, modular PLC automatic control, design layout according to the size and characteristics of the plant, ensuring the rationality of on-site construction and operation, and good On-site working environment; realizes compact layout of workshop equipment and wide space, achieving the economic and aesthetic design effect of modern production workshop;
       Energy-saving design and recycling of thermal energy are considered in all production steps, which greatly reduces energy consumption and saves more than 35% of energy in the same industry. At the same time, the cleaning water in the pre-treatment process considers a certain recycling; Waste such as slag is directly excluded from the production workshop through the screw conveyor system.
       Strictly follow the automation and standardization process to prevent product quality instability caused by human intervention. In each operation, the rationality and fluency of material operation are fully considered. Properly amplify the margin on the basis of meeting the contracted output, and maximize the function and function of each device, so as not to waste one device and not take a step.
       The pipeline process is reasonable, the equipment configuration is high-end and practical, and the utilization rate is extremely high. At the same time, considering the maximum cost savings for customers, it is the basic design concept of the company.

    Flow Chart:
    Aseptic Filling-Pump-Blending System{RO water/Sugar soluble system} - Filltering -Degasser - Homogenizer - UHT Sterilizer - Cans Filling

    2 Ton Per Day Apple Juice Processing Plant Beverage Processing Line

    Major equipment

    NoNameParameter Description
    1Empty can feeding and washing machineProcessing capacity: 200-400 cans / minute
    Power: 2.6kw
    Weight: 2500kg
    Size: 7500mm × 4500mm × 3500mm (length * width * height)
    2Filling and capping machineSize: 2200x1600x1900mm (l*w*h)
    Weight: 2500kg
    Number of filling heads: 12; number of cans: 4
    Filling speed: 6000~9000 cans/hour (250-330g)
    Filling accuracy: ≤±1% Filling amount: according to customer                                                 requirements
    Power : 1.5kw
    Air pressure : 0.6-0.8MPa
    Imported parts for core components
    3Vacuum online leaking machineThe vacuum leak detector uses acoustic technology, non-contact online detection, and speeds of 300 bottles per minute. Used to detect the sealing performance of containers, including leak detection, vacuum testing, empty cans. Applicable to three-piece cans, three-four screw caps, and metal anti-theft caps. Detect unqualified products and automatically reject them.
    4Inkjet printer Size: 600*468*300mm (l*w*h)
    Print tube length: 3 meters Voltage: 220V
    400*600*800mm double stainless steel platform

    Question and answer:
    1. Any guarantee of the machines?
    -YES, one-year free maintenance and life time paid service.
    2. Can you do the OEM design for customers?
    -YES. We could design the capacity, color, mark, Shape and so on according to the customer's requirement.
    3. What is the package of the machines?
    -The machines will be wrapped with plastic film and put in wooden cases.
    4. Shipping port?
    -Shanghai.(Other ports available if required)
    5. Transportation
    -Shipping by sea. Air available if required by customer.

    Our Services Pre-Sales Service
    1.* Inquiry and consulting support.
    2.* Sample testing support.
    3.* Visit our Factory.

    After-Sales Service
    1.* Training how to install and use the machines.
    2.* Engineers available to provide the technique help if necessary.
