SS304 Turnkey Waxberry Beverage Juice Making Machine Processing Line CFM-B-07

SS304 Turnkey Waxberry Beverage Juice Making Machine Processing Line CFM-B-07

    • SS304 Turnkey Waxberry Beverage Juice Making Machine Processing Line CFM-B-07
    • SS304 Turnkey Waxberry Beverage Juice Making Machine Processing Line CFM-B-07
  • SS304 Turnkey Waxberry Beverage Juice Making Machine Processing Line CFM-B-07

    Product Details:

    Place of Origin: China (mainland)
    Brand Name: CFM
    Certification: CE/ISO9001
    Model Number: CFM-B-07-2000

    Payment & Shipping Terms:

    Minimum Order Quantity: 1Set
    Price: negotiable
    Packaging Details: Plastic film and wooden Case
    Delivery Time: 65 Work Days
    Payment Terms: T/T, D/A, L/C, T/T, Western Union
    Supply Ability: 12 sets per year
    Contact Now
    Detailed Product Description
    Name: Waxberry Beverage Line Type: Beverage Production Line
    Color: Silver Bottle Type: Galss Bottle /box Etc.
    Material: SS304 Feature: Full-Automatic,Energy Saving And Easy Operation

    SS304 turnkey wax beverage production line



    ​​Technical advantage
      Taking into account the actual requirements of the customer's factory and the project equipment, the installation and positioning of the production line equipment adopts segmentation positioning, modular PLC automatic control, design layout according to the size and characteristics of the plant, ensuring the rationality of on-site construction and operation, and good On-site working environment; realizes compact layout of workshop equipment and wide space, achieving the economic and aesthetic design effect of modern production workshop;
       Energy-saving design and recycling of thermal energy are considered in all production steps, which greatly reduces energy consumption and saves more than 35% of energy in the same industry. At the same time, the cleaning water in the pre-treatment process considers a certain recycling; Waste such as slag is directly excluded from the production workshop through the screw conveyor system.
       Strictly follow the automation and standardization process to prevent product quality instability caused by human intervention. In each operation, the rationality and fluency of material operation are fully considered. Properly amplify the margin on the basis of meeting the contracted output, and maximize the function and function of each device, so as not to waste one device and not take a step.
       The pipeline process is reasonable, the equipment configuration is high-end and practical, and the utilization rate is extremely high. At the same time, considering the maximum cost savings for customers, it is the basic design concept of the company.


    Flow Chart:



    Yangmei raw materials-cleaning-air drying-nucleating-beating-mixing-filling-cooling-air drying-in storage

    SS304 Turnkey Waxberry Beverage Juice Making Machine Processing Line CFM-B-07


    Major equipment



    No Name Parameter Description
    1 Nuclear unit

    It is specially used for cold cores such as peach, apricot, plum, and bayberry. The main body is made of stainless steel 304. It is first nucleated and then beaten to achieve automatic separation of nuclear meat.



    Processing capacity: 5 tons / hour;
    The material is 304 stainless steel;
    Equipment specifications: 1800mm × 1000mm × 900mm
    Motor power: 2.2KW

    2 Single beater Rated processing capacity 5000KG/H
    Blade speed 1440RPM, continuous
    Mesh diameter head Φ1.0mm
    The part in contact with the material is SUS304 stainless steel
    Motor power: 7.5KW
    Dimensions: 1800*700*900 (length * width * height)
    3 Cooler Capacity: 5T/H
    SUS304 stainless steel
    Specifications: 4200*1100*1938mm (length * width * height)
    Power: 2.2KW (high pressure fan) + 1.5 KW (lift motor)
    Air boiling type (bubbling type:), using mutual friction between raw materials, and friction with "cold water", circulating water, cleaning thoroughly and cleanly.
    4 Box filling machine Nursery boxed Yangmei lock fresh packaging sealing machine Air conditioning Yangmei vacuum filling nitrogen packing sealing machine
    Machine structure
    Aluminum plate part: aluminum alloy acid-resistant aluminum mold, with no deformation, corrosion resistance, high hardness and long service life;
    Rack section: welded with high quality all stainless steel, except the motor box plate.
    Transmission system: motor, reducer, cam splitter, template, drive chain.
    Drop cup system: It is made up of rack, slide rail, storage cup compartment and push cup cylinder. The signal synchronization control action is completed when the template is stopped. Stable and efficient.
    Filling system: The storage tank is made of stainless steel 304 and the size can be customized. The filling volume can be adjusted freely and quantitatively. Measuring cup filling.
    Membrane system: Photoelectric eye tracking automatically corrects the film pattern and cup mouth alignment.
    Sealing system: It is sealed twice by thermostatic (intelligent temperature control).
    Film cutting mechanism: cold punching, cutting out the cover film with easy tearing, easy to open.
    Out cup system: slide rail, slider, variable speed motor, mounting bracket, external conveyor belt.


    Question and answer:


    1. Any guarantee of the machines?
    -YES, one-year free maintenance and life time paid service.
    2. Can you do the OEM design for customers?
    -YES. We could design the capacity, color, mark, Shape and so on according to the customer's requirement.
    3. What is the package of the machines?
    -The machines will be wrapped with plastic film and put in wooden cases.
    4. Shipping port?
    -Shanghai.(Other ports available if required)
    5. Transportation
    -Shipping by sea. Air available if required by customer.
